4.4.2. Clip

Toggles model clipping using the prepared clip box on or off.

Clip Box ribbon menu and icon with 'Clip' selected

Ribbon button: Clip Box > Clip
Command: PiCriClipBox

Behavior:

If no clipping frame has been prepared, a message will appear stating that no frame is defined.
If the model is not clipped, clicking "Clip" applies the clipping box – all geometry outside the box is hidden.
If the model is already clipped, clicking "Clip" removes the clipping and restores full visibility.

The clipping status is maintained in the drawing, so it persists across save/close/reopen cycles.
