5.1.14. ExportAttribute, Module 2 Settings
On this page
Overview
This option is used in the SuCri2ExportPrimarySupport function to export supports to Advance Steel as special parts. It specifies which properties of the support are written to attributes 01 to 10 of the exported part. The assignment is made from left to right: the first property in the list is assigned to attribute 01, the second to attribute 02 and so on up to attribute 10.
Where can I find the setting?
Open the Settings window with the command SuCriSettings or via the Settings button in the SuCri ribbon. On the left, select the Module 2 tab, then the General subtab, Export primary support group. There the setting is called Exported attributes (01-10). Apply changes with Save.
Values
The default value of the ExportAttribute setting is Tag, LineNumberTag, PartSizeLongDesc.
Possible values: comma-separated list of property names of the support, at most ten.
Example
Example value
Related setting
In the same group, Group export by SU number (ExportGroupBySuNo, activated by default) specifies whether each exported primary support is stored in a subfolder with its SU number.
Associated function
This setting belongs to the commands 4.2.5. Export supports (SuCri2ExportPrimarySupport) and 4.2.24. Export selected supports (SuCri2ExportPrimarySupportForSelection).
