5.3.32. ShowPlateCoordinate, Module 4 Settings
On this page
Overview
Determines whether the coordinates of the plate center axes are to be annotated for a section in a top view: 0 - Off: The coordinates of the plate center axes are not displayed. 1 - On: The coordinates of the plate center axes are displayed. Note: This function currently does not support all plates.
Values
The default value of the ShowPlateCoordinate setting is 1.
Possible values:
- 0: Off
- 1: On
Example
Value 0 (Off)
Value 1 (On)
Related function
Auto Views, Auto Drawings.
