5.3.19. SetUCSForLayoutPlan, Module 4 Settings

Updated on 07/09/2026

Overview

Coordinate display in WCS or UCS: Determines whether the coordinates on the layout plan are to be displayed in the world coordinate system (WCS) or in the user coordinate system (UCS).

Values

The default value of the setting SetUCSForLayoutPlan is WCS.

Possible values: Show coordination in WCS or UCS

Example

Value Beispiel
SetUCSForLayoutPlan: Value Beispiel (Platzhalter)

Related feature

This setting belongs to the Automatic views, Automatic drawings feature.
