5.3.35. RoundProfileLength, Module 4 Settings

Overview

Defines the number of decimal places to which the measured length L and the height H are rounded in the dialog for creating typicals. This setting has no effect on the bill of materials or the dimensioning of the ortho drawings.

• 0: 100, no decimal places
• 1: 100.1, one decimal place
• 2: 100.12, two decimal places

For rounding dimensions in ortho drawings, there is the setting Dimension decimals (RoundDimention) in the Settings window, tab Module 4, subtab General, group Dimensions.

Where can I find the setting?

This setting is not shown in the Settings window. It can only be changed directly in the file sucri4_settings.json in the CommonData folder of the Module 4 plug-in package (entry RoundProfileLength, field Value). When you save in the Settings window, the entered value is preserved. Back up the file before making a change.

Values

The default value of the setting RoundProfileLength is 2.

Possible values:

• 0: 100
• 1: 100.1
• 2: 100.12

Example

Value 0 (100)

Value 1 (100.1)

Value 2 (100.12)

Related function

This setting belongs to creating typicals (Module 5).
