5.3.21. HiddenLineMode, Module 4 Settings
On this page
Overview
Options for hidden lines: 0 - No hidden lines: No hidden lines are displayed. 1 - Hidden lines in isometric view: Hidden lines are shown only in the isometric view. 2 - Hidden lines in all views: Hidden lines are displayed in all views. 3 - Hidden lines in all views, except in the layout plan: Hidden lines are shown in all views except in the layout plan.
Values
The default value of the setting HiddenLineMode is 0.
Example
Value Beispiel
Related feature
This setting belongs to the Automatic views, Automatic drawings feature.
