5.3.29. TOSAnnotationOrientation
On this page
Overview
Determines how the COP (center of pipe) coordinate annotation is oriented:
- 0, Same as other annotation: The COP annotation is treated like the other annotations.
- 1, Horizontal, left/right of the view: The COP annotation is placed horizontally to the left or right of the view.
Note: In earlier versions of the manual, this setting was referred to as TOSAnnotationOrientation (TOS annotation, top of steel). A setting with this name does not exist in SuCri.
Where can I find the setting?
Open the Settings window with the command SuCriSettings or in the SuCri ribbon via the Settings button. On the left, select the Module 4 tab, then the General subtab, group Annotation. There, the setting is called COP annotation orientation. Apply changes with Save.
Values
The default value of the COPAnnotationOrientation setting is 1.
Possible values:
- 0: Same as other annotation
- 1: Horizontal, left/right of the view
Example
Example value
Related function
This setting belongs to the Auto Annotations function, for example 4.5.11. Annotate view with ortho annotations (SuCri4PlantOrthoAnnotate).
