5.1.9. MTOInlayLength, Module 2 Settings

Overview

This setting defines the calculation method for inlay bands that are ordered in rolls by the meter. During the MTO export, SuCri adds up the lengths (circumferences) of the inlay bands per item. The output quantity is this total length divided by the set value, rounded up to whole rolls. With the value 10, 23.4 m of inlay band is therefore output as 3 rolls.

Where can I find the setting?

Open the Settings window with the command SuCriSettings or in the SuCri ribbon via the Settings button. On the left, select the Module 2 tab, then the General subtab, group MTO export. There, the setting is called Inlay band length (m). Apply changes with Save.

Values

The default value of the MTOInlayLength setting is 10 (rolls of 10 m).

Possible values: decimal number from 0, roll length in meters.

• 1: rolls of 1 m
• 10: rolls of 10 m
• X: any roll length X in meters, for example 2
• 0: no roll calculation; the total length is output rounded to one decimal place

Example

Value 1 (1M)

Value 10 (10M)

Value X (XM) (e.g. 2M)

Related function

This setting belongs to the function MTO (SuCri2GetReport).
