5.1.4. SpaceBelowStructure, Module 2 Settings
On this page
Overview
This option is used in the Turbo Tools to identify, in the automatic selection for multiple supports, pipes that are located below a structure and whose height is below a defined value (Value). It offers a quick and efficient way of filtering support points based on the relative position of pipes.
Where can I find the setting?
Open the Settings window with the command SuCriSettings or on the SuCri ribbon via the Settings button. On the left, select the Module 2 tab, then the General subtab, Turbo Tools group. There, the setting is called Space below structure. Apply changes with Save.
Values
The default value of the SpaceBelowStructure setting is 5000 (mm).
Possible values: decimal number from 0, in millimeters. In projects with inch units, SuCri automatically converts the value to the project unit.
Example
Value example
Related function
This setting belongs to the Turbo Tools function, for example 4.2.6. Support [x] (SuCri2AutoSelectMultipleSupport).
