5.3.28. AnnotationPlacementMethod
On this page
Overview
Determines whether annotations, including item numbers, are placed near the body edge (Clear space) or around the views (Exterior): 1 - Exterior: Annotations are placed around the views. 2 - Clear space: Annotations are placed in the nearest free area.
Values
The default value of the setting AnnotationPlacementMethod is 2.
Possible values:
- 1: Exterior
- 2: Clear space
Example
Value 1 (Exterior)
Value 2 (Clear space)
Related feature
This setting belongs to the Automatic views, Automatic drawings feature.
