5.3.33. MinDimFromEdge, Module 4 Settings
On this page
Overview
Defines the minimum distance in mm between the first dimension chain and the body edge.
Values
The default value of the setting MinDimFromEdge is 10.
Possible values: mm.
Example
Value Beispiel
Related feature
This setting belongs to the Automatic dimensioning feature.
