5.3.37. ExtendPipelengthinviews
On this page
Overview
This extension value extends the ortho cube from the center point of the support to both ends of the pipe so that more of the pipe geometry is shown in the view.
Values
The default value of the setting ExtendPipelengthinviews is 0.
Possible values:
- 0: no extend
- 100: extend 100mm
Example
Value example
Related function
Auto Views, Auto Drawings.
