5.3.36. DrawingLanguage, Module 4 Settings
On this page
Overview
Defines the language of the texts that SuCri writes in ortho drawings, for example view titles. The setting selects the language column in the language map: ENG (English), DEU (German) or another language column.
You maintain the translations in the Settings window, Module 4 tab, Language map subtab, with one column per drawing language.
The drawing language is independent of the product language of the SuCri user interface.
Where can I find the setting?
Open the Settings window with the command SuCriSettings or in the SuCri ribbon via the Settings button. On the left, select the Module 4 tab, then the General subtab, Naming and language group. The setting is called Drawing language there. Apply changes with Save.
Values
The default value of the setting DrawingLanguage is ENG.
Possible values in the window: ENG, DEU.
An additional language column from the language map can only be selected by a direct entry in the file sucri4_settings.json.
Example
Example value
Related function
Auto views and drawings, for example 4.5.12. Create single drawing (SuCri4PlantOrthoCreateMultiple) and 4.5.13. Create multiple drawings (SuCri4PlantOrthoCreateMultipleSU).
